Wildcat 240RS Race-Spec Engine

The Wildcat 240RS is a standout small-block engine offering the largest displacement in its class, combined with top-tier factory upgrades. This means you get a high-performance powerhouse without the need for immediate modifications or teardown. Designed to excel across a broad range of applications—from spec kart racing and highly modified racing builds to mild or wild minibikes—the 240RS delivers unparalleled versatility and value. Best of all, we’ve made this performance accessible by keeping the price incredibly competitive. Simply put, you won’t find another engine delivering this level of performance at this price point.

Important Notices:

• Dyno-Tuned Before Shipping: Each engine is dyno-tuned using a karting fuel tank with a 1/4" vent and fuel pump. Using stock or certain aftermarket mini bike fuel tanks with venting through the fuel cap or check valves can pressurize the carburetor, causing a rich running condition. This is a venting issue, not a tuning problem. You may need to modify your tank by adding a 1/4" vent fitting open to atmosphere for proper function.

• Float Bowl Handling: Engines are run before shipping. Shipment may cause the carburetor float to stick. If rich running persists after resolving tank venting, remove the float bowl, check float movement, and ensure the needle valve operates smoothly.

• Engine Mounting Angle: The engine runs best mounted flat or up to an 8° angle. Mounting at a greater angle—due to motor mounts or chassis rake—can cause hesitation or stumble at low speeds.

• Exhaust Recommendations: Avoid stock mufflers, screw-on styles, “weenie pipes,” or any exhaust with an ID smaller than .900". Restrictive exhausts cause the engine to run rich and lose performance. Use headers with a minimum .900" ID.

Dyno and Performance Resources

• Dyno Comparison Video: Watch here

• Dyno Comparison Blog: Read more

Engine Specifications & Highlights:

• Displacement: 240.11cc with a 72mm bore and a 59mm stroke crankshaft—the largest small block displacement available, equivalent to Honda’s smallest big block. Think of it as the “427ci LS” of minibike and kart engines.

• Cylinder Head: The Wildcat WC946 head features 31mm intake and 25mm exhaust stainless steel valves with billet retainers, offering significantly more flow and durability than typical small block valves. Learn more about the WC946 head here.

• Carburetor: The upgraded WC22 26mm slide carburetor is expertly blueprinted and tuned in-house for optimal performance, delivering a clean air-fuel ratio of 12-13:1 on high-octane pump gas (best under 1800 ft elevation, call before ordering if you are over 1800ft). This carb is a proven upgrade over competitors, backed by dyno results.

• Camshaft: The included Banzai 265 camshaft is a benchmark for mini bike and kart engine upgrades, designed to clear the 59mm crankshaft without modifications, delivering enhanced power right out of the box.

• Flywheel & Ignition: The lightweight cast aluminum flywheel safely handles up to 8500 RPM. Rev limiting is controlled by a 6100 RPM coil (similar to the Ghost 212). For RPMs above 7000, upgrading to a billet rod and high-RPM coil is recommended.

• Spark Plug: We’re the first to include a fine-wire iridium spark plug, which improves power by 0.2–0.3 HP by providing a more focused and consistent spark under high cylinder pressure and richer fuel mixtures.

• Top Plate & Fuel Pump: Designed for near turnkey installation, the included top plate and fuel pump work seamlessly with the WC22 carburetor, especially when the stock fuel tank is not elevated enough to gravity-feed properly. Elevated tanks may require bypassing the pump.

• Soft Grip Pull Rope: A small but quality upgrade—durable, comfortable soft-grip handle instead of cheap plastic.

• Break-in Oil: Includes Maxima Racing Break-in Oil. Break-in requires running the engine under load, not free revving, between 3500–5500 RPM for 15–20 minutes (practice sessions work great). After break-in, switch to Maxima Racing RS 0W-20 or 5W-30 for best performance.

Technical Specs:

Specification

Detail

Displacement

72mm Bore x 59mm Stroke = 240.11cc

Cylinder Head

WC946, 18cc chamber, 31/25mm valves, billet retainers

Compression Ratio

~11:1 (Recommended 91+ octane, non-ethanol fuel)

Carburetor

WC22 26mm Slide Carburetor with short matched intake

Camshaft

Banzai 265 Lift on 224 core (no clearance needed)

Ignition Coil

6100 RPM Limited Coil (No internal governor)

Other Features

Reinforced Block, Aluminum Flywheel, Cast Rod, Top Oil Fill, Fuel Pump

Recommended Upgrade Path:

• Billet Rod & Non-Rev Limited Coil: Handles RPMs above 6100 and improves ignition timing for increased power. Uses the 8270 billet rod.

• Billet Flywheel: The SK201 lightweight billet flywheel features 34° ignition timing and a stronger magnet for enhanced spark and RPM capability.

• Head Porting: The WC946’s large valves offer huge potential—porting can significantly boost performance without additional parts.

• PWK24 Flat Slide Carburetor: For added performance beyond the WC22 without internal engine mods. Recommended to move to a 28mm flat slide carburetor when increasing camshaft/rocker arm specs.

• Advanced Upgrades: At this stage, modify the head for dual valve springs, install bigger cams and ratio rockers, and switch to chromoly pushrods cut to length.

Billet Intake Adapter for PWK Carburetors – Fits Honda GX200 / Clone Engines

The EC 472INT Billet Aluminum Intake Manifold is engineered to adapt PWK-style spigot-mounted carburetors (24mm to 28mm) to Honda GX200 and 196cc clone engines. Whether you're building a high-performance mini bike, kart, or race engine, this intake offers the precision, strength, and features enthusiasts and racers demand.

Precision Fit & Performance Design

Unlike low-cost cast intakes with generic shapes, this adapter is CNC-machined to match the D-shaped intake port common on GX200-style cylinder heads. However, due to manufacturing variations and aftermarket porting, some heads may require minor port matching for a perfect seal — especially Hemi heads or modified castings.

Built for Durability & Secure Mounting

Where other intakes fail to hold the carburetor under high vibration or aggressive riding, the 472INT shines:

• Carb Boot Locking Groove: Precision-machined groove ensures a tight, secure grip with the recommended rubber carb boot (#515 – sold separately).

• Stabilizer Bracket: A custom-fit bracket bolts the intake to the carburetor, preventing accidental separation — ideal for trail riding, mini bikes, or racing applications.

• Pulse Fitting Included: Supports vacuum-operated fuel pumps for reliable fuel delivery at all RPMs.

Application Compatibility

Designed to fit most GX200-style small block engines, including:

• Honda GX200 / 196cc Clone Engines

• Box Stock Project 196

• Tillotson 196R / 212 / 225 / 228 / 236 / 268

• Ducar 196 / 212 / 224

• Predator 212 (Hemi & Non-Hemi)

• Predator 224

• Wildcat 223 / 240

• Ghost 212

Note: Hemi heads(especially Ducar/Tillotson/Ghost) often have slightly offset ports. Fitment is not an issue, but port matching may be necessary for optimal airflow.

What’s Included

• CNC Billet Intake Manifold

• Intake Gasket

• Pulse Fitting (pre-installed)

• Mounting Bolts

• Stabilizer Bracket + Bracket Hardware
  (Carburetor may require tapping to accept bracket bolts – #10-24 tap recommended)

Carburetor Boot (#515) sold separately. Use with EC's PWK Carb Kits for guaranteed compatibility.

Technical Specs:

• Overall Length: 41.25mm (1.625")

• Spigot OD: 34.95mm (1.375")

• Spigot ID (tapered): ~27.95mm (1.100")

• Compatible Carb Sizes: 24mm to 28mm PWK Spigot Carbs

Due to varying carb designs (Keihin, Nibbi, Mikuni, Walbro, etc), please measure your carb spigot or use EC’s matched PWK carburetor kits for best fitment.

FAQ

Q1: Will this intake fit my Predator 212 engine?

Yes, it fits both Hemi and Non-Hemi versions of the Predator 212. However, Hemi heads may have a slightly offset intake port, so we recommend port-matching for optimal performance.

Q2: What size PWK carburetors does this adapter support?

This intake supports 24mm to 28mm PWK-style spigot-mount carburetors. Always verify the spigot outer diameter (OD ~34.95mm) and inner diameter before installation.

Q3: Do I need the carburetor boot (#515)?

Yes. The carb boot (#515, sold separately) is essential for securely attaching the carburetor to the intake. The intake features a locking groove designed specifically for this boot.

Q4: Is a fuel pump required?

Not always, but if you're running a fuel system that requires vacuum assistance, the intake includes a pulse fitting to connect a fuel pump.

Q5: Will this fit a stock Honda GX200 engine?

Yes, it fits stock GX200 heads and most clone variants. For original Honda heads, ensure the intake port shape matches or be prepared to port match slightly for a precision fit.

Q6: Does this come with everything I need for installation?

The kit includes:

• Billet intake manifold

• Gasket

• Mounting bolts

• Carburetor stabilizer bracket with hardware

• Pulse fitting

You will still need a carburetor boot (#515) and potentially a tap (#10-24) for bracket mounting.

Q7: Can this be used for racing or trail riding?

Absolutely. The stabilizer bracket prevents carburetor separation under harsh vibration, making it suitable for mini bikes, karts, and high-performance race builds.

Q8: Can I use other brands of PWK carburetors?

Yes, but since spigot diameters vary slightly between brands and knock-offs, always check your carb's OD and ID to ensure proper fit — or use EC's PWK carb kits for guaranteed compatibility.

Billet Velocity Stack for PWK 21–30mm Slide Carburetors – 2.5" Air Filter Adapter

Upgrade your airflow and filter compatibility with EC’s Billet Velocity Stack, designed for PWK 21mm to 30mm slide carburetors. This precision-machined velocity stack adapts your carburetor to accept standard 2.5-inch (63.5 mm) air filters, offering improved performance, smoother airflow, and enhanced filtration options.

Perfect for mini bikes, go-karts, and high-performance small engine builds, this stack not only boosts throttle response but also ensures a snug, secure fit for cone-style filters.

Key Features:

• CNC-machined billet aluminum for strength and heat resistance

• Allows PWK 21mm–30mm slide carbs to run 2.5-inch air filters

• Tapered design improves airflow velocity and reduces turbulence

• Lightweight yet durable—built for track and off-road abuse

• Sleek finish to complement race-ready carb setups

Dimensions:

• Outer Diameter (OD): 2.5 inches / 63.5mm

• Inner Diameter (ID): 1.960 inches / 50mm

• Always verify carburetor dimensions for proper fitment

Whether you're tuning a high-RPM mini bike or dialing in your go-kart for race day, this billet velocity stack helps you get more from your PWK carb setup—both in performance and compatibility.

FAQ

What does this velocity stack fit?

This billet velocity stack is designed to fit PWK-style slide carburetors from 21mm to 30mm that feature a standard round spigot. Always measure your carb to confirm compatibility.

What size air filter does it support?

It adapts your carburetor to accept 2.5-inch (63.5mm) air filters—common in performance cone-style filters used in karting and mini bike builds.

What does a velocity stack do?

A velocity stack improves airflow by reducing turbulence at the intake, which can enhance throttle response and power, especially in mid-to-high RPM ranges.

Will this velocity stack increase performance?

Yes, when paired with a properly tuned carburetor and a performance air filter, it can enhance airflow, improve throttle response, and increase top-end performance.

What material is it made from?

This stack is CNC-machined from billet aluminum, offering excellent durability, heat resistance, and a precise fit.
