The 8288 EC Pinnacle Billet Connecting Rod is precision-engineered to solve common clearance issues found when upgrading small engines like the Predator 224 Non-Hemi, Ducar 212, Tillotson 212E, and Ghost 212. Specifically designed with a 3.303-inch center-to-center length, this rod features optimized geometry to reduce interference between the rod dipper and camshaft.(Predator 224 will have some clearance-ing for the rod to pass the cylinder bore due to the bearing increase the size of the big end of the rod)

Unlike standard clone rods, the 8288 is built to accommodate the .715" wrist pin, found in Ducar and Tillotson performance engines, and is not compatible with Predator 212 (Hemi or Non-Hemi) or Predator 224 Hemi engines. Whether you're building a high-revving kart engine or performance mini bike, this rod provides increased strength, better balance, and a proper fit for today’s larger displacement small blocks.

Key Features & Benefits

• Designed for .715" Wrist Pins
  Fits Ducar 212, Tillotson 212E, Ghost 212, Predator 224 Non-Hemi

• Improved Camshaft Clearance
  Solves rod dipper interference common in Predator 224 builds

• High-Strength Billet Construction
  CNC-machined from premium billet aluminum for durability at high RPM

• Complete Rod Assembly
  Includes bearings and rod bolts—ready for installation

• Balanced for High-Performance Use
  Built for engines pushing higher power in race or performance settings

Rod Specifications:

• Rod Length (center-to-center): 3.303"

• Weight (without bearings): 137g

• Wrist Pin Journal: .715" diameter

• Crankshaft Journal: 1.180" (Standard Clone Fit)

• Compatibility: Predator 224 Non-Hemi, Ducar 212, Tillotson 212E, Ghost 212

• Not Compatible With: Predator 212 (Hemi or Non-Hemi), Predator 224 Hemi

What's Included:

• 1x 8288 EC Pinnacle Billet Connecting Rod

• 1x 8394 High-Performance Bearings

• 2x 8383 Rod Bolts

Rod Bolt Torque Spec: 150 in/lbs (12-point 1/4” socket required)

FAQ

Will this rod fit a Predator 212 engine?

No, the 8288 rod is not compatible with Predator 212 (Hemi or Non-Hemi) or Predator 224 Hemi engines. It is designed for larger wrist pin applications like the Predator 224 Non-Hemi, Tillotson 212E, Ghost 212, and Ducar 212.

What size wrist pin does this rod support?

The rod is made to fit a .715-inch wrist pin, which is standard in Ducar, Tillotson, and Ghost 212 performance engines.

Is the rod ready to install out of the box?

Yes. The 8288 rod comes complete with precision bearings and rod bolts. Just be sure to torque bolts to 150 in/lbs and verify clearances during engine assembly.
